5m carport
CHF0.00
Tags:
Product ID
23500
Weight [kg]
698
Inner length [mm]
4840
Inner width [mm]
2000
Inner height [mm]
2000
Outer length [mm]
5000
Outer width [mm]
2200
Outer height [mm]
2200
Dimensions in transport position [mm] (L×W×H)
5000x2200x380
Door type
Double-wing
Door position
2 walls
Delivery
To order
Product Details
Specification
Container is made out of galvanized steel sheets 0,75 mm thick.
Supportive profiles are made out of galvanized steel sheets 2,0 mm thick.
Floor is made out of wooden planks 35 mm thick (system tongue groove).
Assembled container can be dismounted to transport position to reduce cost of transportation.
Container has double-wing door (in front and side wall) with handle, lock and stoppers.
Double-wing door in the middle of side.
Wall are used for leaving as standard parts are supplied drive-in ramp and stopping bar.
Enhance profile when door is fully opened is 1930 x 1930 mm.
Handling
It is possible to move Assembled container with crane or forklift truck. To hang it on a crane has each corner angle of the container crane hug.
Protection of Container
With a container can be delivered a Vandal bar. A user can also equip it with standard protection system using sensor and alarm.
Maximal Load
by handling with crane - 1500 kg | by handling with forklift truck - 3000 kg
of floor surface - 500 kg/m² | of foor surfacewith stiffeninf - 300 kg/m²
Accessories and Special Equipment
Lot of different accessories and special equipment can be installed, see categories.
